Decorative Colored Aluminum Coil

As one of the most professional decorative colored aluminum coil manufacturers in China, we're featured by quality products and customized service. Please rest assured to buy bulk decorative colored aluminum coil in stock here from our factory.

Online consultation

Project Introduction

●Stable and high quality , customized aluminum products can be produced.

●Excellent professional technical support.

●Sales people that act as an extension of your purchasing department (we will get any metal products you need).

●Support of Just-in-Time manufacturing processes.

Decorative Colored Aluminum Coil

Product	decorative colored aluminum coil
Alloy	1050 1060 1100 3003 3004 3105 5052 6061
Thickness	0.3-3.0mm
Width	500-2000mm
Length	Any length is ok, so long as it is suitable for transportation
Surface	Mill finish, Flat, Clean, embossed colored, Any one will be ok. As customers' request.
Film / Paper	Can be blue film coated or not, also can be paper between each sheet
MOQ	3 MT, or depend on the SPECIFICATION .
Production Line	DC and CC
Coating Thickness	PE coating: 15~18 micron
Coating Thickness	PVDF coating: 25~28 micron
Application	Roofing, Insulation for tank or power plat, car box ,decoration etc.
Kind attn	Custom Made, if any questions, pls do feel free to contact us.

Decorative colored aluminum coil & sheet is to make the wire drawing on the aluminum surface by mechanical friction or extrusion process, then make one layer of special film treatment on the aluminum surface. which generate one layer containing this metallic composition on the aluminum roll surface, clearly appear each fine wire lines. So let the metal take fine gloss. Then make the chemical treatment in our modern chemical treatment production line, after that make PVDF or Polyester (PE) Coating in solid colors or metallic colors through the color coating production line.

Professional cutting line,to make sheet with any length;

So different specification of decorative colored aluminum coil are available,we provide customized service.

Product	Surface Treatment	Thickness Range	Width Range	Length Range
PVDF decorative colored aluminum coil	PVDF Coating 25~28MIC	0.3~3.0MM	Max 2000MM	Coil & Sheet
PE painted aluminum coil	PE Coating 15~18MIC	0.3~3.0MM	Max 2000MM	Coil & Sheet

Decorative Colored Aluminum Coil

Alloy	Main metal element
1000 series	Al ≥ 99.0%
2000 series	Al-Cu Al-Cu-Mg
3000 series	Al-Mn Al-Mn-Mg
4000 series	Al-Si
5000 series	Al-Mg Al-Mg-Mn
6000 series	Al-Mg-Si
7000 series	Al-Zn Al-Zn-Mg-Cu
7000 series	An-Sn

Decorative Colored Aluminum Coil

Alloy	Temper	Tensile Strength	Yield Strength	Elongation (%)		Tensile Strength	Yield Strength
Alloy	Temper	(ksi)	(ksi)	0.01-0.05 in	0.051-0.125 in	(MPa)	(MPa)
1100	H12	16	15	4	12	110.3	103.4
1100	H14	18	17	3	10	124.1	117.2
3003	H12	19	18	9	11	131	124.1
3003	H14	22	21	3	7	151.7	144.8
3004	H32	31	25	6	15	213.7	172.4
3004	H34	35	29	5	10	241.3	199.9
3005	H12	26	24	5	13	179.3	165.5
3005	H14	29	28	4	9	199.9	193.1
5005	H12	20	19	5	9	137.9	131
5005	H14	23	22	4	7	158.6	151.7
5052	H32	33	28	7	10	227.5	193.1
5052	H34	38	31	6	8	262	213.7
5056	O	42	22	23	24	289.6	151.7
5056	H38	60	50	6	13	413.7	344.7
6061	T4	35	21	22	24	241.3	144.8
6061	T6	45	40	12	17	310.3	275.8
7075	O	33	15	16	18	227.5	103.4
