Factors influencing the mechanical properties of 6 series aluminium alloy

Today we are talking about the factors influencing the mechanical properties of 6 series aluminium alloy. And if you need to buy 6 series aluminum alloys, please contact us Haomei aluminum.

(1) Homogenisation of aluminium alloy ingot billets

Homogenization treatment can improve the plasticity of the ingot billet, enhance its technological properties, improve the anisotropic properties of the product organization and eliminate the residual stress inside the metal. (Unqualified companies may not carry out homogenization treatment)

2) Extrusion temperature and speed of aluminium profiles

6063, 6063A its quenching temperature shall not be lower than 500 degrees, so the extrusion temperature is generally controlled at 470 --- 490 degrees, 6061, 6A02 its delivery state is generally T6, quenching temperature is slightly higher than 6063 about 510 ----520 degrees. Specific extrusion temperature and extrusion speed should be adjusted according to the profile wall thickness, extrusion characteristics and die conditions and other factors, adhere to the principle of high temperature and low speed, low temperature and high speed extrusion. However, its exit temperature shall not be lower than the product quenching temperature.

(3) Quenching effect of aluminium profiles

Quenching is in order to solid solution in the base metal at high temperature Mg2Si in the die after the rapid cooling to room temperature and be retained, the cooling rate is often proportional to the content of the strengthening phase, because of its quenching sensitivity increased in Mg2Si for 0.8% of 6063 alloy, from 454 degrees to 204 degrees in the critical cooling temperature range, the minimum cooling rate of 38 degrees / min, and containing 6061 alloy with 1.4% Mg2Si should have a cooling rate of no less than 65 degrees/min in the above critical cooling temperature range, therefore, 6063 can be quenched by air cooling and 6061 must be quenched by water cooling. Uniform and good quenching effect can effectively improve the mechanical properties of the product.

(4) Artificial ageing of aluminium profiles

6063, 6061 alloy profile in the state of just extruded tensile strength equal to or greater than 140 MPa, in the rapid cooling to room temperature within 8 hours after artificial aging can make its tensile strength enhanced to 240 MPa or more, artificial aging is generally used 190 --- 200 degrees insulation 1 --- 2 hours. 6061, 6A02 is generally used 180 --- 190 degrees insulation 4 --- 6 hours. ---6 hours. (Specific operations should be carried out according to the wall thickness of the profile, chemical composition and order requirements)

In the process of production management of aluminium profiles, the above extrusion process parameters can be effectively controlled to obtain good mechanical properties of the products. 6063 and 6063A can ensure that their Vickers hardness is greater than or equal to 12. 6061 and 6A02 can have Vickers hardness greater than or equal to 15. and meet the requirements of various products to a large extent.
